How Docker images are built

Why it's not as simple as you think

Looking at the following Dockerfile one might assume the resulting image might be smaller than the original ubuntu image.

FROM ubuntu:latest

RUN rm -rf /usr

But in reality, it's larger in size. The reason for this is the way images are stored and built.

Introducing layers

Docker uses a category of file systems called union file systems, more specifically OverlayFS. OverlayFS works by overlaying one or several read-only directory trees (lowerdir1 and lowerdir2) and a single (or none) writable directory tree (upperdir), resulting in a merged single writable directory tree (merged).

Let's look at the following imaginary OverlayFS filesystem. Be aware we always operate on the merged view of the directory tree.

Scenario 1: Reading file1

When trying to read/access file1 in the merged directory tree, it will actually read file1 of lowerdir1.

Scenario 2: Reading file2

When trying to read/access file2 in the merged directory tree, it will actually read file2 of lowerdir1. Even though file2 is both present in lowerdir1 and lowerdir2 the upper layers will "overlay" the layers below.

Scenario 3: Overwriting file1

When overwriting an already existing file inside the merged directory tree, like file1 in this example, the base file in lowerdir1 won't actually be overwritten (Remember: All lowerdirs are always read-only), instead a new copy with the edits made will be created inside upperdir, leaving the base file untouched.

Scenario 4: Deleting file3

When deleting an file that exists in one of the lowerdir, a so called "whiteout" file is created (inside a special overlayfs directory) which marks the file as deleted. Inside the merged directory tree, no file will be present.

Attention: When deleting a file inside the upperdir, the file will actually be deleted.

Scenario 5: Creating file4

When creating a new file, the file will be created inside the upperdir directory tree.

Summary

• All writes or deletes always happen on the upperdir (or in case there is none, they will fail).
• All reads will access the file inside the most upper layer, in which it exists.

Why docker images can't decrease in size

Using this newly gained knowledge of how OverlayFS works, let's go back to our original observation of the docker image that can't decrease in size.

Docker images are built out of layers, which map to dirs/layers in OverlayFS. Each build instruction inside a Dockerfile will first start a new container mounting an OverlayFS as root filesystem with all previously built layers as lowerdirs (read-only) and a newly created layer as upperdir (read/write). Once the build step is completed (in the above case rm -rf /usr) it will commit the upperdir as a new readonly layer/lowerdir.

Therefore the above docker image will actually be larger in size due to a new layer that contains white-out files.

The next step

In the second part of this series we will explore, what to do, in order to keep docker images small, leveraging the knowledge of how the docker filesystem works.
